| Camera |
Image Sensor |
2K CMOS |
|
Max. Resolution |
2304 (H) × 1296 (V) |
|
Min. Illumination |
0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR |
|
Angle Adjustment |
Pan: 0–360°, Tilt: 0–90°, Rotation: 0–360° |
| Lens |
Lens Type |
2.8 mm / 3.6 mm Fixed Focal Lens |
|
FOV (2.8 mm) |
Horizontal: 105°, Vertical: 60°, Diagonal: 129° |
|
FOV (3.6 mm) |
Horizontal: 89°, Vertical: 47°, Diagonal: 107° |
| Illuminator |
Light Range |
IR: Up to 25m, White Light: Up to 20m |
|
Light Modes |
Smart, IR, and White Light |
| Audio |
Microphone |
Built-in Mic; Pickup radius up to 5 m |
| Image |
Enhancement |
Digital WDR, BLC, HLC, Global, Smart IR |
|
Frame Rate |
TVI: 2K @20fps, 1080p @25/30fps |
| Interface |
Video Output |
Switchable TVI/AHD/CVI/CVBS |
| General |
Material |
Plastic |
|
Power |
12 VDC ± 25%, Max. 3.9 W |
|
Protection |
IP67 Water and Dust Resistant |
|
Dimensions |
138.8 mm × 60.9 mm × 57.9 mm |
