- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 55°, diagonal FOV: 125°
3.6 mm, horizontal FOV: 84°, vertical FOV: 45°, diagonal FOV: 99°
- Lens MountM12
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 20 m
- Smart Supplement LightYes
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness, Sharpness, Anti-banding, AGC
- Frame Rate
TVI: 1080p @25 fps/30 fps
CVI: 1080p @25 fps/30 fps
AHD: 1080p @25 fps/30 fps
CVBS: PAL/NTSC
- Day/Night ModeColor
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementDWDR, BLC, HLC, Global
- Noise Reduction3D DNR/2D DNR
- White BalanceAuto, Manual
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- AlarmSolid Light Alarm (White Light)
- General
- MaterialPlastic
- Power12 VDC ± 25%, max. 2 W,*You are recommended to use one power adapter to supply the power for one camera.
- Dimension161.1 mm × 68.4 mm (6.34″ × 2.69″)
- Approx. 389 g (0.86 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Approval
- ProtectionIP67
