 Specification
Display
Screen Size 21.5 inch
Active Display Area 478.656 (H) mm × 260.28 (V) mm
Resolution 1920 × 1080
Backlight E-LED
Pixel Pitch 0.0831 (H) mm × 0.241 (V) mm
Brightness 250 cd/m² Viewing Angle 178° (H) / 178° (V)
Color Depth 8 bit ,16.7 M
Contrast Ratio 1000 : 1
Response Time 1 ms
Refresh Rate 100 Hz
Haze Haze 25%, 3H
Reliability 7 × 16H
Color Gamut 72% NTSC
Interface
Video & Audio Input HDMI 1.4 × 1, VGA × 1
Video & Audio Output Audio Out × 1
Data Transmission Interface NA
Control Interface NA
Power
Power Supply DC 12V, 2.0A
Power Consumption ≤ 24 W
Standby Consumption ≤ 0.5 W
Working Environment
Working Temperature 0℃ to 40 ℃ (32 ℉ to 104 ℉ )
Working Humidity 20% to 90% RH (Non-Condensing)
Storage Temperature -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉ )
Storage Humidity 10% to 90% RH (Non-Condensing)
General
Casing Material Plastic
VESA 75 mm × 75 mm (4 – M4 × 6 mm)
Bezel Width 2.38 mm (top/left/right), 21.55 mm (bottom)
Product Dimensions (W × H × D)
With base: 493.26 (W) mm × 369.12 (H) mm × 162.75(D) mm(19.42 (W) × 14.53 (H) × 6.41 (D)) inch
Without base: 493.26(W) mm × 290.14 (H) mm × 42.68 (D) mm(19.42 (W) × 11.42 (H) × 1.68 (D)) inch
Package Dimensions (W × H × D)
598 (W) mm × 391 (H) mm × 106 (D) mm
(23.54(W) × 15.39 (H) × 4.17 (D) ) inch
Net Weight 2.0 ± 0.5 kg (4.4 ± 1.1 lb)
Gross Weight 3.2 ± 0.5 kg (7.1 ± 1.1 lb)
Packing List
Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable(1.5m) ×1, User manual × 1, Multilingual manual × 1
Remarks The metal base is included by default.
The product appearance and parameters in this specification may vary fromyour
actual device. Please consult our local sales staff for further information
